Voltas 1.5 Ton 3 Star Inverter Split AC (Model 183INV CAV) User Manual

परिचय

This manual provides essential information for the safe and efficient operation, installation, and maintenance of your Voltas 1.5 Ton 3 Star Inverter Split AC, Model 183INV CAV. Please read this manual thoroughly before using your air conditioner and retain it for future reference.

मुख्य विशेषताहरु

• इन्भर्टर कम्प्रेसर: Variable speed compressor adjusts power based on heat load, offering energy efficiency.
• Convertible 5-in-1 Cooling Mode: Adjusts cooling capacity via remote for different needs and energy savings.
• क्षमता: 1.5 Ton, suitable for medium-sized rooms (111 to 150 sq ft).
• उर्जा रेटिंग: 3 Star, with an Annual Energy Consumption of 900.94 kWh/year and ISEER Value of 4.30.
• Copper Condenser: Ensures superior heat transfer, durability, and resistance to rust and corrosion.
• विशेष सुविधाहरू: Anti-dust Filter with Anti Microbial Coating, Auto Clean, Memory Restart, Sleep Mode, Gas Leak Detection, 5 fan speed levels, 2-way air swing, Hidden Display, Wide Operating Range, LCD Remote, Long Air Throw.
• फ्रिज ग्यास: R32, an environmental-friendly refrigerant with no ozone depletion potential.

छवि विवरण: An energy savings guide for the Voltas AC, detailing the 3-star rating, ISEER value of 4.30, and annual energy consumption. It also highlights the BEE logo and AC model details.

सेटअप र स्थापना

Proper installation is crucial for optimal performance and longevity of your AC. It is recommended to have the unit installed by a certified technician.

बक्समा के छ:

• १ भित्री एकाई
• १.१ बाहिरी इकाई
• 1 Interconnecting Cable (9.84 ft)
• 1 Set (2 nos) Interconnecting Pipe (Copper, 9.84 ft)
• 4 Outdoor Vibration Pads
• २०१२ रिमोट कन्ट्रोल
• २ एएए रिमोट ब्याट्रीहरू
• 1 Indoor Mounting Plate
• Plastic Sleeves + Screws for Indoor Mounting Plate

छवि विवरण: A visual representation of the components included in the Voltas AC package, showing the indoor unit, outdoor unit, remote, insulated copper line set, and small accessories.

उत्पादन आयाम:

• Indoor Unit (W x H x D): ३७ x १७ x १७ सेमी
• Outdoor Unit (W x H x D): ३७ x १७ x १७ सेमी

छवि विवरण: An image illustrating the dimensions of both the indoor and outdoor units of the Voltas AC, providing measurements in centimeters.

नियुक्ति विचारहरू:

Ensure at least 2 feet of clear space around the indoor unit for optimal airflow and cooling performance. The unit offers maximum piping flexibility up to 15 meters, allowing for versatile installation options.

सञ्चालन मोडहरू

Your Voltas AC features a Convertible 5-in-1 Cooling Mode, allowing you to adjust the cooling capacity to suit your needs and save energy. Use the remote control to select the desired mode.

• Mode 1 (Mid Cooling): For energy saving when less cooling is required.
• Mode 2 (Gentle Cooling): Ideal for up to 2 people.
• Mode 3 (Moderate Cooling): Suitable for up to 3 people.
• Mode 4 (Accelerated Cooling): Great for a group of up to 5 people.
• Mode 5 (Turbo Fast Cooling): Provides super-fast cooling for more than 5 people or when rapid cooling is needed.

छवि विवरण: A graphic illustrating the five adjustable cooling modes of the Voltas AC, showing different scenarios and the number of people each mode is suitable for, along with the Sleep Mode feature.

रिमोट कन्ट्रोल कार्यहरू:

The LCD remote control provides easy access to all functions, including power ON/OFF, temperature controls, mode selection (Auto, Cool, Dry, Fan), fan speed adjustment, V-swing/H-swing, Timer ON/OFF, TEMP Display/Settings, Anti-Freeze, and SST (Sleep Set / Sleep Mode).

छवि विवरण: A detailed image of the Voltas AC remote control, with labels pointing to each button and its corresponding function, such as LCD Display, Power, Temperature Controls, Mode, Fan Speed, Swing, Timer, and Sleep Mode.

शीतलन प्रविधि

Copper Condenser:

The AC is equipped with a 100% copper condenser, ensuring efficient heat transfer and enhanced durability. Copper's natural resistance to corrosion contributes to the long-term performance of the unit.

छवि विवरण: एउटा कोलाज शोasing the Gold Fin Condenser and Evaporator with Zero Performance Drop, Anti-Corrosive Coating for Zero Rust, 100% Copper Condenser for Zero Heat Loss, and Anti-Freeze Thermostat for Zero Freeze.

High Ambient Cooling:

Designed to provide comfortable cooling even when outside temperatures reach extreme highs, up to 52°C. The robust engineering ensures consistent performance in challenging conditions.

Anti-Freeze Thermostat:

This crucial safeguard prevents the indoor unit's coils and pipes from freezing when temperatures drop too low, protecting the system and ensuring continuous operation.

Air Quality Features

Anti-dust Filter with Anti Microbial Coating:

The removable anti-dust filter, enhanced with an anti-microbial coating, effectively traps dust particles and prevents the growth of microbes, ensuring clean and fresh air in your room. This also helps in preventing bad odors.

छवि विवरण: A graphic highlighting the Anti Dust Filter with Anti Microbial Coating for dust-free, germ-free freshness, anti-fungi technology to beat mold, and super dry mode for humidity-free comfort.

Hydrophilic Gold Fin Evaporator:

The hydrophilic gold fin evaporators are designed to keep the cooling coil dry, preventing corrosion and enhancing heat exchange for more reliable and long-lasting cooling performance.

आराम सुविधाहरू

मेमोरी रिस्टार्ट:

In the event of a power cut, the Memory Restart feature automatically restores your previous settings once power is resumed, ensuring uninterrupted comfort without manual intervention.

निद्रा मोड:

The Sleep Mode intelligently adjusts the temperature throughout the night, maintaining optimal comfort for restful sleep while also conserving energy.

2-Way Air Swing:

The 2-way air swing feature ensures uniform cooling distribution across the room, eliminating hot spots and providing consistent comfort.

छवि विवरण: A graphic detailing comfort and safety features including Memory Restart for auto-restart after power cut, 2-Way Air Swing for uniform cooling, Sleep Mode for adjustable temperature, and Gas Leak Detection for worry-free cooling.

सुरक्षा सुविधाहरू

ग्यास चुहावट पत्ता लगाउने:

The AC is equipped with a Gas Leak Detection system. If a gas leak is detected, the unit will display an 'EC' warning and automatically alert the service system, which will then contact you to arrange support.

FR Grade Material on Indoor PCB Box:

The indoor PCB box is constructed with FR (Fire Retardant) grade material, adding an extra layer of protection and ensuring the safety of the core electronic components.

मर्मतसम्भार

Regular maintenance ensures the efficiency and longevity of your Voltas AC.

• फिल्टर सफाई: Regularly clean the anti-dust filter to maintain optimal airflow and air quality. The filter is removable for easy cleaning.
• स्वतः सफा गर्ने कार्य: Utilize the auto clean feature to prevent mold and bacteria buildup on the evaporator coil.
• व्यावसायिक सेवा: Schedule periodic professional servicing to check refrigerant levels, clean coils, and ensure all components are functioning correctly.

समस्या निवारण

If you encounter any issues with your AC, refer to the following basic troubleshooting steps before contacting customer support:

• कुनै शक्ति छैन: पावर कर्ड सुरक्षित रूपमा प्लग इन गरिएको छ कि छैन र सर्किट ब्रेकर ट्रिप भएको छ कि छैन जाँच गर्नुहोस्।
• अपर्याप्त शीतलन: Ensure the air filter is clean, doors and windows are closed, and the temperature setting is appropriate.
• असामान्य आवाजहरू: Minor noises during operation are normal. If loud or unusual noises occur, contact customer support.
• पानी चुहावट: Check if the drain hose is properly connected and not blocked.
• त्रुटि कोडहरू: If an error code appears on the display (e.g., 'EC' for gas leak), note the code and contact customer support.

निर्दिष्टीकरणहरू

वारेन्टी र समर्थन

Your Voltas AC comes with comprehensive warranty and dedicated customer support.

• उत्पादन वारेन्टी: 1 Year Comprehensive Warranty on the Product.
• कम्प्रेसर वारेन्टी: 10 Years Warranty on Inverter Compressor.
• PCB वारेन्टी: 5 Year Warranty on PCB.

Warranty claims should be made with your Amazon Invoice. For further details, the user manual is available on the Brand Webसाइट।

ग्राहक समर्थन:

Voltas offers reliable 24x7 customer support across a wide network.

• इमेल: vcare@voltas.com
• फोन: +919650694555 / 1860-599-4555

छवि विवरण: A graphic detailing Voltas's customer support, including coverage in over 18000+ pin codes and 100% of Tier 1 cities, along with email and phone contact information.
